Airfield Lighting Cables are used to secure airport equipment such as aircraft taxiways, runway navigational aids, and obstruction lights, and can be directly buried or ducted.
About ensuring the safe operation and landing of airports, Hongtai Cable Airport Lighting Cables has developed a range of solutions that are resistant to problems such as water, UV rays, oil, and grease, and that ensure the continuous and stable operation of airport runways, taxiways, and airport building lighting systems. In addition, our airport cable solutions cover a full range of services, from cable design by application-specific requirements and national standards to on-site international logistics.
| FAA L-824 Type C Sheathed 5kV Airfield Lighting CableConductor: Stranded bare Copper Conductor, IEC 60228 class 2 FAA L-824 Type C Sheathed 5kV Airport Lighting Cable is used to connect transformers and current regulators in series circuits for airport lighting systems and is suitable for stationary applications such as aircraft taxiways, runway navigational aids, and obstruction lights, and can be buried or ducted. Standard: IEC 60502, IEC 332-3, IEC 60228, FAA AC 150/5345-7E |
| FAA L-824 Type B Unshielded 5kV Airport Lighting CableConductor: Stranded bare or tinned copper conductor Insulation: EPR Outer Semi-Conductor: Extruded semi-conducting compound. Out Sheath: HDPE/PVC Voltage Uo/U (Um): 5kV Operating Temperature: -40℃~+85℃ Minimum bending radius: 5×OD Halogen-free: Yes Oil Resistant: Yes FAA L-824 Type B Unshielded 5kV Airport Lighting Cable is used to connect transformers and current regulators in series circuits for airport lighting systems and is suitable for stationary applications such as taxiways, runway aids, and obstruction lights, and can be buried or ducted. Standards: FAA L-824 Type B, ICEA S-96-659/NEMA WC71 |
| FAA L-824 Type C 600V Airfield Lighting CableConductor: ASTM B multi-strand bare copper conductor. Insulation: XLPE. Sheath (for Multi-Core cables only): PVC. Voltage Uo/U (Um): 60kV Maximum conductor temperature: 90℃ Short circuit temperature: 250℃ Operating Temperature: -40℃~+90℃ Minimum bending radius: 5×OD FAA L-824 Type C 600V airfield lighting cable is suitable for airport lighting and control circuits and is suitable for both conduit and direct burial laying. Standards: FAA L-824 Type C, ICEA S-95-658/NEMA WC71 |
| H07RN-F Airport Lighting CableConductor: Stranded bare copper Insulation: Special cross-linked elastomer / EPR Sheah: Special cross-linked elastomer / EPR Operating Voltage: U0 450/750V Maximum Conductor Temperature: 85℃ Short Circuit Temperature: 200℃ Operation Temperature: -20℃ to + 85℃ Minimum Bending Radius: Static: 4×OD; Dynamic: 8×OD H07RN-F airfield ground lighting cable for connection between transformers and airport lighting equipment. Standards: NF C 32-102-4, HD 22-4 |
| 400Hz Single-Core Airport CableConductor: VDE 0295/IEC 60228 standard Class 5 multi-strand copper conductor. Insulation: TPE. Voltage Uo/U (Um): 600V Maximum Conductor Temperature: -40°C~+90°C Short circuit temperature Static: 6×OD; Dynamic: 7×OD Halogen-free: Yes Abrasion resistant: Yes 400Hz single-core airport cables are suitable for 400Hz systems for aircraft power, computer systems, and radar stations and are suitable for laying underground, underwater, outdoors, indoors, and in cable ducts. Standard: VDE 0295 |
Service of Hongtai Cable Company
Over Productions Service: Hongtai Cable has a wide range of cable and conductor products for you to choose from. We will provide caring services and professional project solutions for everyone who needs them.
Quality Certification Services: Hongtai Cable products are manufactured according to GB, IEC, BS, NFC, ASTM, DIN, and other international standards. Our technical team can customize cable products that meet your requirements according to your needs.
Profession Customer Service: Hongtai Cable provides free professional consulting services to provide you with one-stop project solution services and rapid product delivery solutions.
Delivery And Shipping Services: While we at Hongtai Cable provide high-quality cables, we also provide good delivery solutions. While ensuring the safe delivery of products, we provide the best packaging and transportation solutions, greatly reducing customers’ transportation costs.
Packaging of Hongtai Cable: Hongtai Cable packaging is provided in the form of wooden reels, corrugated boxes, and coils. The cable ends are sealed with BOPP self-adhesive tape and a non-hygroscopic sealing cap to protect the cable ends from moisture. We can print the required marks on the outside of the barrel with waterproof material according to customer requirements.
